Alarm guide
How to Change an Intruder Alarm Battery: What You Can Do Yourself
A low-battery warning on an intruder alarm is easy to put off and easy to handle badly. Some batteries are made to be changed by the person using the system. Others sit inside a mains-powered panel or an external sounder and are not. This guide explains how to tell which is which, what you can reasonably do yourself, and when to stop.
What an intruder alarm battery warning means
A low-battery warning means that part of the system has detected that its battery is running down. It is a request for attention, not a sign that the alarm has failed, but it should not be left. A device that runs out of power stops doing its job.
A system is made of several parts, and each can have its own battery and report its own condition. The control panel, the detectors, the keypad, any remote fobs and an external sounder can all be affected, and the wording used varies from one system to another.
Work out which device needs the battery
Before buying or changing anything, find out which part of the system is reporting the warning. The usual places to look are:
- the message on the keypad or panel display, or in the system’s app if it has one;
- an indicator light or message on the detector, keypad or fob itself; and
- the manufacturer’s user manual, which explains what each message and indicator means for that system.
Identify the device from the message, the indicator or the manual. You should not need to open any cover to find out which battery is low, and opening one is not a way to investigate.
Which batteries can you usually replace yourself?
Some devices are designed to have their batteries changed by the user as a routine job. Wireless detectors, keypads and remote fobs are the usual examples. Where that is the case, the manufacturer provides user instructions that say so and explain how.
That does not mean every device of the same type can be treated the same way. Whether a battery is user-replaceable is decided by the manufacturer for each product, so the user instructions for your own system are the only reliable guide.
Only if the manufacturer says so
User-replaceable device
- A wireless detector designed for routine battery changes
- A keypad or remote fob with a battery the user instructions say you can change
Follow the manufacturer’s user instructions and use the battery they specify.
Not a DIY job
Service-only component
- A mains-powered alarm control panel
- An external sounder or bell box
- A sealed or internal battery, or anything behind a tamper-protected cover
Use the manufacturer’s service procedure or a competent alarm engineer.
Before replacing a user-serviceable battery
- Read the manufacturer’s user instructions for that specific device.
- Confirm that the instructions describe the battery as one the user can replace.
- Use the battery type specified by the alarm manufacturer, and nothing else.
- Keep clear of any mains-powered or service-only part of the system while you do it.
If the instructions are not to hand, or they do not say the user can change the battery, stop there and treat it as a job for the manufacturer’s service procedure or an engineer.
General replacement principles
For a battery that the manufacturer says the user can replace, the sequence is always the manufacturer’s own:
- Identify the device that is reporting the warning.
- Read the manufacturer’s user instructions for that device.
- Confirm the battery is intended to be replaced by the user.
- Obtain the replacement battery the manufacturer specifies.
- Remove and fit the battery using the manufacturer’s method for that device.
- Close the device and check the system status.
The detail of steps 5 and 6 differs between products, which is why they are left to the instructions rather than set out here.
What to do after replacing the battery
Check whether the warning has cleared. Some systems update straight away and others take a short time to register the change, so follow what the manufacturer says about how and when the status should update.
Then confirm that the device is behaving normally and that the system is showing a healthy status. There is no universal way to clear a warning, and nothing here should be treated as one.
What if the low-battery warning stays on?
If the warning is still showing after the battery has been replaced, there are a few general possibilities:
- the device that was changed was not the one reporting the warning;
- the system has not yet recognised the new battery;
- another device in the system is also low;
- there is an underlying fault; or
- the battery involved is a service-only one that the user cannot reach or change.
Re-check the message against the manufacturer’s instructions once. If it persists, do not keep trying different things. A warning that will not clear has stopped being a battery-change job.
When to call an alarm engineer
Stop and get qualified help if any of the following applies:
- the battery is inside the control panel, or is a sealed or internal battery;
- the battery is in a bell box or external sounder;
- the system is hard-wired, or the work would involve power or isolation of any kind;
- the warning involves tamper or a service message rather than a simple low-battery one;
- the warning remains after the battery has been replaced; or
- you are not certain which device is affected, or whether it is safe to touch.
Silencing or hiding a warning is not the same as fixing it. A system left in a fault state may not protect the property as it should.
Conclusion
Some alarm batteries are meant to be changed by the user, and some are not. The manufacturer’s instructions decide which, and anything inside a mains-powered panel, an external sounder or a sealed unit belongs with the manufacturer’s service procedure or an engineer.
If the warning stays on, or the battery is not one you can safely reach, you can find out more about intruder alarm repair and servicing in Manchester, or get in touch to talk it through.
